Cable Diagnostic On-Switch Application

Version 1.1.0.3

• added support for -p PORTLIST command line option

Minimum ExtremeXOS Required

EXOS 21.1.2

EXOS 22.5

An EXOS command which invokes the cablediag.py applicaiton has been added to EXOS 22.5.

run diagnostics cable ports [ <port_list> | all ]

Files

Cable Diagnostic Application Download

File	Description
summitX-cablediag-1.1.0.3.xmod	Summit Cable Diagnostic Application
onie-cablediag-1.1.0.3.xmod	ONIE Cable Diagnostic Application

Overview

The cablediag.py application performs a Time Domain Reflectometry (TDR) diagnostic on copper switch interfaces.

Download

To update your Extreme EXOS switch with this version of cablediag.py:

1. Using the right mouse button, copy the link of the desired .xmod above
2. On an EXOS Command line enter: download url <paste the link from above>

EXOS Command Line

cablediag.py is managed using the run script CLI command.

Help

To see the cablediag options, enter

run script cablediag.py -h

usage: cablediag [-h] [-p PORTLIST [PORTLIST ...]] [-d]

optional arguments:
  -h, --help            show this help message and exit
  -p PORTLIST [PORTLIST ...], --portList PORTLIST [PORTLIST ...]
                        Port list separated by a "," or "-"
  -d, --debug           Enable debug

Default behavior

Perform a diagnostic on all copper interfaces carrying user data. Copper interfaces used for stacking are not included in the diagnostic.

--p or --portList

Specify individual port or ports.

Individual ports may be:

• a single port
• multiple ports separated by a comma ‘,’
• A range of ports specified by a dash ‘-‘ between a beginning and ending port.

Running cablediag.py

run script cablediag.py

Or EXOS 22.5 and later

run diagnostics cable ports all

cablediag: 1.1.0.3


+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
+                             C A U T I O N                             +
+   cablediag will momentarily interfere with traffic on active ports   +
+-----------------------------------------------------------------------+
+   Ports: All Ports                                                    +
+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
Do you want to continue cable diagnostics? [y/N]: y

Collecting port cable diagnostic information may take a moment...
port 1: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 2: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 3: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 4: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

.
.
.
port 24: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

CABLEdiag: ERROR: port 25: Feature unavailable

CABLEdiag: ERROR: port 26: Feature unavailable

CABLEdiag: ERROR: port 27: Feature unavailable

CABLEdiag: ERROR: port 28: Feature unavailable

In the example above, ports 25-28 are not copper ports used for user data.

Running cablediag.py with Ports

run script cablediag.py -p 1-4,9-15,40,41

Or EXOS 22.5 and later

run diagnostics cable ports 1-4, 9-15, 40,41

cablediag: 1.1.0.3


+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
+                             C A U T I O N                             +
+   cablediag will momentarily interfere with traffic on active ports   +
+-----------------------------------------------------------------------+
+   Ports: 1,2,3,4,9,10,11,12,13,14,15,40,41                            +
+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
Do you want to continue cable diagnostics? [y/N]: y

Collecting port cable diagnostic information may take a moment...
port 1: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 4 meters
        pair B Ok, length 0 meters
        pair C Ok, length 0 meters
        pair D Ok, length 0 meters

port 2: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 3: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 4: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 9: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 5 meters
        pair B Crosstalk, length 1 meters
        pair C Ok, length 0 meters
        pair D Crosstalk, length 1 meters

port 10: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 11: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 4 meters
        pair B Ok, length 0 meters
        pair C Ok, length 0 meters
        pair D Ok, length 5 meters

port 12: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 13: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 191 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 14: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 10 meters
        pair B Ok, length 5 meters
        pair C Ok, length 9 meters
        pair D Ok, length 10 meters

port 15: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 40: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 0 meters
        pair B Ok, length 0 meters
        pair C Ok, length 0 meters
        pair D Ok, length 0 meters

port 41: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 0 meters
        pair B Ok, length 0 meters
        pair C Ok, length 0 meters
        pair D Ok, length 0 meters

Running cablediag.py on a Stack

run script cablediag.py 1:1,1:3,1:9-16,2:1-5,2:13

Or EXOS 22.5 and later

run diagnostics cable ports 1:1,1:3, 1:9-16, 2:1-5,2:13

cablediag: 1.1.0.3


+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
+                             C A U T I O N                             +
+   cablediag will momentarily interfere with traffic on active ports   +
+-----------------------------------------------------------------------+
+   Slot 1: Ports: 1,3,9,10,11,12,13,14,15,16                           +
+   Slot 2: Ports: 1,2,3,4,5,13                                         +
+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
Do you want to continue cable diagnostics? [y/N]: y

Collecting port cable diagnostic information may take a moment...
Slot 1
port 1: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 5 meters
        pair B Ok, length 0 meters
        pair C Ok, length 0 meters
        pair D Ok, length 0 meters

port 3: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 9: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 5 meters
        pair B Crosstalk, length 1 meters
        pair C Ok, length 0 meters
        pair D Crosstalk, length 1 meters

port 10: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 11: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 4 meters
        pair B Ok, length 5 meters
        pair C Ok, length 4 meters
        pair D Ok, length 4 meters

port 12: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 13: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 14: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 5 meters
        pair B Ok, length 7 meters
        pair C Ok, length 5 meters
        pair D Ok, length 5 meters

port 15: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

port 16: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters

Slot 2
port 1: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 0 meters
        pair B Ok, length 0 meters
        pair C Ok, length 0 meters
        pair D Ok, length 0 meters
port 2: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 5 meters
        pair B Ok, length 4 meters
        pair C Ok, length 4 meters
        pair D Ok, length 2 meters
port 3: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters
port 4: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters
port 5: cable (4 pairs, length +/- 10 meters)
        pair A Open, length 0 meters
        pair B Open, length 0 meters
        pair C Open, length 0 meters
        pair D Open, length 0 meters
port 13: cable (4 pairs, length +/- 10 meters)
        pair A Ok, length 4 meters
        pair B Ok, length 0 meters
        pair C Ok, length 2 meters
        pair D Ok, length 0 meters
