Viewing Appliances
From the SD-WAN Orchestrator main menu, select the Administration -> Appliances function to view the assigned appliances.
The following image shows that three ip|e 40ax have been assigned to Customer 'Nile'. You may use the filters at the top of the window for exclusive display.
Appliance Parameters
Owner
Customer name.
Serial Number
The Serial Number is made of 12 characters as follows: MmmyyEnnnnRr, where:
| • | M: Manufacturer initials |
| • | mm: month of manufacture (01 to 12) |
| • | yy: year of manufacture (18 for 2018) |
| • | E: engine (appliance) type |
|
W |
ip|e 30so |
|
X |
ip|e 30ax |
|
I |
ip|e 40so |
|
J |
ip|e 40ax |
|
U |
ip|e 40so V2 |
|
V |
ip|e 40ax V2 |
|
K |
ip|e 400ax |
|
A |
ip|e 2000ax-T |
|
B |
ip|e 2000ax-Sx |
|
C |
ip|e 2000ax-Lx |
|
D |
ip|e 2000ax-10GSr |
|
E |
ip|e 2000ax-10GLr |
| • | nnnn: serial n° (0001 to 9999) |
| • | Rr: revision (R for major revision, r for minor revision): starting with A0 |
Example: A0218X0001A0 corresponds to a Serial Number of the first ip|e 30ax manufactured by Aaeon on February 2018.
Status
An appliance is In Stock when available or Assigned when it has been assigned to the current Customer.
Model
Refer to the previous table of appliance types.
Tag
ZTP appliance tag code.
Software Version
Version of software services.
Last Connection (UTC)
Last time when the SD-WAN Orchestrator synchronized data with the ZTP Server.
