Changing the Network Operating System

ExtremeSwitching Universal Hardware switches can run two different operating systems: Switch Engine (default) or Fabric Engine.

Making Your Initial Network Operating System Selection

You can make your initial selection of the operating system using:
  • ExtremeCloud IQ (see ExtremeCloud IQ Agent Support)—You can select your network operating system when purchasing your switch, which associates the switch serial number with your desired network operating system, which then causes the desired network operating system to be loaded during ExtremeCloud onboarding. For more information about using ExtremeCloud IQ, go to https://www.extremenetworks.com/support/documentation/extremecloud-iq/.
  • ExtremeCloud IQ Site Engine— see documentation for version 22.3 or later
  • Manually during boot-up:
    • Bootloader—When you see the message Starting Default Bootloader ...Press and hold the <spacebar> to enter the bootrom, press and hold the space bar until the boot menu is displayed (you have 30 seconds):
      *** 5320-48T-8XE Boot Menu ( 3.4.2.8 ) ***

     EXOS: Default
     EXOS: Primary 32.1.1.6
     EXOS: Secondary 32.1.1.6
     EXOS: Primary 32.1.1.6 with default configuration
     EXOS: Secondary 32.1.1.6 with default configuration
     EXOS: Rescue
     Change the switch OS to VOSS
     Run Manufacturing Diagnostics
     Update bootloader
     Reboot system

      Use the up and down arrow keys to select Change the switch OS to VOSS, and then press Enter.

      Note

      Note

      The 5720, 7520, and 7720 Series use the GRUB menu. There is no need to press and hold the space bar. Use the up and down arrow keys to navigate the menu.
    • Safe defaults mode start-up menu—When the question Would you like to change the switch OS to VOSS? [y/N/q] is displayed:
      • For Switch Engine, type N.
      • For Fabric Engine, type y.

    Continue to log onto the switch. For more information about logging onto the switch, see the Switch Engine 32.7.1 User Guide .

Changing Your Network Operating System

You can change your network operating system selection at any time.
Caution

Caution

Changing your network operating systems deletes all configuration files, debug information, logs, events, and statistics information of the previous network operating system.
Note

Note

If you anticipate ever changing the operating system to Fabric Engine, and you want to statically assign IP addresses on the DHCP server, then it is recommended to assign them based on the DHCP client ID. For more information about this issue, see the Using a BOOTP or DHCP Server topic in the Switch Engine 32.7.1 User Guide .
