Extreme 7720 Switch Features

The Extreme 7720 switch includes the following models:

7720-32C

The 7720-32C base switch includes six empty fan module slots and two empty power supply module slots. Fan modules and power supply modules must be ordered separately.

7720-32C-AC-F

The 7720-32C-AC-F switch includes two AC power supply modules and six fan modules. Airflow for both the fan modules and the powers supply modules is front-to-back.

7720-32C-AC-R

The 7720-32C-AC-R switch includes two AC power supply modules and six fan modules. Airflow for both the fan modules and the powers supply modules is back-to-front.

The front panel of the switch includes:

• 1 = 32 x 40/100Gbps QSFP28 ports
• 2 = Serial console port (RJ-45)
• 3 = USB Type-A port for management or external USB flash
• 4 = 10/100/1000BASE-T Out-of-band management ports

7720-32C Switch Front Panel

The rear panel of the switch includes:

• 1 = Grounding lug
• 2 = 6 x Fan modules
• 3 = 2 x Power supply slots

Note

The color of the tab on the fan tray indicates the airflow direction:

• Red: front-to-back
• Blue: back-to-front

7720-32C Switch Rear Panel
