Restore Backup File

Use this procedure to restore the appliance from a selected configuration backup file.

  1. Go to Administration > System > Configuration.
  2. Select the Backup/Restore tab.
  3. If no backup file displays under Select Backup, then complete the following steps to upload the backup file:
    1. Under Restore, select , then select Upload.
    2. Select the Upload Method. Valid values are:
      • HTTP
      • FTP
      • SCP
    3. If you chose HTTP as the upload method, do either of the following and then select Close:
      • Select Choose Backup file, then browse to the backup file and select it
      • Use the cursor to drag and drop the backup file from a local drive onto the desktop.
      Click to expand in new window
      Upload Controller Image
      Upload Controller Image Dialog
    4. If you chose FTP or SCP, enter the remore server details and then select OK:
      • Server IP—Enter the IPv4 address of the remote server.
      • Username—Enter a username that has access to the remote server.
      • Password—Enter the password that authenticates the username on the remote server.
      • Directory—Enter the directory where the backup file is saved.
      • Filename—Enter the filename of the backup file.
      • Destination—Enter the upload destination. For example, Local.
  4. From the Select Backup drop-down, select the uploaded backup file.
  5. Run the restore job.
9039323-00 Rev. AA
