Use clear commands to remove information
about the internal state of IPv6 PIM. Use the debug command to enable debug flags for
troubleshooting. You can run the commands from any level of the CLI. For more
information, see the Extreme SLX-OS
Command Reference.
Important
Diagnostic commands are developed and
intended for specialized troubleshooting. Work closely with Extreme Networks
technical support in running debug commands and interpreting their results.
Remove the RP-to-group mappings
from the static IPv6 PIM forwarding table.
device# clear ipv6 pim rp-map
Clear the IPv6 PIM forwarding
cache.
device# clear ipv6 pim mcache
Remove the IPv6 PIM traffic
counters.
device# clear ipv6 pim traffic
Enable debug flags.
device# debug ipv6 pim parameter
Parameter
Flag to enable
add-del-oif
OIF change
bootstrap
Bootstrap processing
group
Group processing
join-prune
Join and Prune processing
nbr-change
Neighbor changes
packets
Packet processing
parent
Parent change processing
route-change
Route changes
rp
Rendezvous Point processing
source
Source processing
state
State processing
all
State of all flags
Display the status of all IPv6
PIM debug flags.
device# show debug ipv6 pim
PIM debugging status:
--------------------------
add-del-oif : off
bootstrap : off
group : off
join-prune : on
nbr-change : off
packets : off
parent : off
regproc : on
route-change : on
rp : off
source : off
--------------------------
