The network automatically adds access points when the DHCP and DNS prerequisites are met. You can save time by configuring the AP before installation using pre-provision mode. You can revert the AP to production mode when you are ready for deployment.
Note
Confirm that Domain Name System (DNS), Network Time Protocol (NTP), and the firewall ports are configured and available before deployment. Create a firewall rule to allow outbound traffic from Extreme Networks devices. For more information about firewalls, see Firewall Configuration Guides.You should configure the DHCP options on your DHCP server to assign an allowed NTP server to Extreme Networks devices. Both DNS and NTP are critical for country and region detection and certificate validation.
Important
Before you install your AP, read the deployment and onboarding information in ExtremeCloud IQ Controller Deployment Guide for on-premises deployments or the Extreme Platform ONE Networking User Guide for a Cloud deployment.
Extreme Networks devices, including access points, require firmware updates to ensure optimal performance and security. During deployment, upgrade your APs to the latest firmware. For more information, see ExtremeCloud IQ Controller Deployment Guide for on-premises deployments or the Extreme Platform ONE Networking User Guide for a Cloud deployment.
Warning
Do not stack APs on top of each other during onboarding or configuration. This may cause heat to build up between the APs, damaging the radomes and voiding the warranty.Use the information in the following table to help you install your access point.
| Steps | Action | Purpose |
|---|---|---|
| 1 | Confirm that your AP and accessories arrived complete and undamaged. | |
| 2 | Install the access point to one of the following: | Install the AP on a ceiling or wall, and connect the network cable. If you use Power over Ethernet (PoE), then the AP powers up. The AP begins a discovery process to determine its own IP address and the IP address of the controller. When the discovery process is successful, the AP registers with the controller. For more information, see the following articles:
|
| 3 | (Optional) Connect to a power supply. | Connect to an external 12-volt DC power supply if you are not using Power over Ethernet (PoE). Note: Your Extreme AP must be grounded so it can be used safely. Consider this requirement when you plan your deployment.
|
| 4 | Connect the AP to your network. |
Connect the AP to your network using a network cable and one of the Ethernet ports. Login to ExtremeCloud IQ Controller and set the operating system (OS) and region. See the "Onboarding Universal APs — ExtremeCloud IQ" section of the ExtremeCloud IQ Controller Deployment Guide. Note: Universal APs are configured for cloud management by default. To manage these APs locally, specify Local Management when onboarding in ExtremeCloud IQ.
|
| 5 | (Optional) Onboard the AP with the ExtremeCloud IQ Mobile Onboarding application. | Scan the QR code or bar code on the back of the device and begin the onboarding process. |
| 6 | Confirm that the LED is white. | A white LED indicates that your AP has powered up and registered with the Cloud. An amber light indicates a technical issue that requires a resolution. See the Led Descriptions section in the "Overview" chapter for an explanation of the LED states. |
| 7 | (Optional) Lock the access point. | Secure the AP and prevent someone from removing it. |
