The 5120-44X-4Y-2C switch includes the following models:
5120-44X-4Y-2C
The 5120-44X-4Y-2C base switch includes two unpopulated modular power supply slots and six unpopulated fan slots. Fan modules and power supply modules must be ordered separately.
5120-44X-4Y-2C-AC-F
The 5120-44X-4Y-2C-AC-F switch includes one AC power supply module, one unpopulated modular power supply slot, and six fan modules. Airflow for both the fan modules and the powers supply modules is front-to-back.
5120-44X-4Y-2C-AC-R
The 5120-44X-4Y-2C-AC-R switch includes one AC power supply module, one unpopulated modular power supply slot, and six fan modules. Airflow for both the fan modules and the powers supply modules is back-to-front.
5120-44X-4Y-2C-TAA
The 5120-44X-4Y-2C-TAA base switch includes two unpopulated modular power supply slots and six unpopulated fan slots. Fan modules and power supply modules must be ordered separately. The 5120-44X-4Y-2C-TAA base switch is TAA compliant.
5120-44X-4Y-2C-AC-F-TAA
The 5120-44X-4Y-2C-AC-F-TAA switch includes one AC power supply module, one unpopulated modular power supply slot, and six fan modules. Airflow for both the fan modules and the powers supply modules is front-to-back. The 5120-44X-4Y-2C-AC-F-TAA switch is TAA compliant.
The front panel of the switch includes:
1 = 44 x 1Gb/10Gb SFP+ ports (ports 1 through 12 support 100Mbps)
2 =
4 x 1Gb/10Gb/25Gb SFP28 Universal/stacking ports
