Overview

Important

The AP4020FX (SKUs AP4020FX-WW and AP4020FX-WW-TAA) is only available in the USA and Canada because of the 6 GHz external ports.

The AP4020FX is an ExtremeCloud IQ managed, Wi-Fi 7 (802.11be) universal indoor access point (AP). It has a quad-radio design with three 2x2:2 radios for use across the 6 GHz, 5 GHz, and 2.4 GHz bands. It also features a dedicated sensor and dual IoT radios.

The AP4020FX supports six optional RP-SMA antennas which you can attach to the AP and use to extend your coverage. You can use any of the supported antennas documented in the Supported Antennas section of Accessories.

You can operate the AP in one of two modes:

• Mode 1: 2.4 GHz /5 GHz/6 GHz data radios and sensor
• Mode 2: 2.4 GHz, and dual 5 GHz, and sensor

It can be mounted to a ceiling, wall, beam or junction box. The AP4020FX ships with the AH-ACC-BKT-AX-TB mounting bracket for use on flat t-bar ceiling grids and flat surfaces.

The AP4020FX must run under standard power regulatory rules and follow Automated Frequency Coordination (AFC) regulatory rules.
