Static anycast gateway functionality provides support for seamless VM mobility across the leaf switches in IP Fabric deployments.
Hosts attached to the leaf switches are configured with a default gateway, which is typically the IP address of the leaf switch in the VLAN facing the host. If this host moves to another leaf switch, the host has to be reconfigured with the IP address of the new leaf switch to which it is now connected as its default gateway.
To make this movement of host from one leaf switch to another seamless, all the leaf switches are configured with the same anycast IP address and the associated virtual MAC (VMAC or anycast MAC) address for a given VLAN/BD. This configuration allows any leaf switch to behave as the default gateway for the host and allows for the most optimal forwarding behavior.
The ingress leaf switch recognizes the VMAC address as its own MAC address and does Layer 3 forwarding.
As shown in the following figure, for VLAN 10, all leaf switches are configured with the same MAC address and IP address.
When the host sends an ARP request for the gateway IP address on VLAN 10, the ingress leaf switch intercepts the ARP request and responds with the VMAC address associated with anycast IP. This behavior is controlled for each VE interface.
Note
Static anycast gateway is recommended only in the presence of a BGP EVPN control plane.In order to configure static anycast gateway, configure the VMAC address first by specifying the default MAC address or an arbitrary unicast MAC address as in the following IPv4 and IPv6 examples. The default MAC address values are 02e0.5200.0100 and 02e0.5200.0200 for IPv4 and IPv6, respectively.
device(config)# ip anycast-gateway-mac default-mac device(config)# ipv6 anycast-gateway-mac default-mac device(config)# ip anycast-gateway-mac 0000.0101.0101 device(config)# ipv6 anycast-gateway-mac 0000.0101.0102
The anycast gateway IP address can be configured under the VE interface for VLANs/BDs, as in the following example.
device(config)# vlan 100 device(config-vlan-100)# router-interface ve 100 device(config-vlan-100)# int ve 100 device(config-if-Ve-100)# ip anycast-address 100.0.0.1/24 device(config-if-Ve-100)# ipv6 anycast-address 1000::1/24
Note
An IPv4 and IPv6 anycast MAC address cannot be configured as the same MAC address.The configured anycast gateway address can be seen in the following examples.
device# show ip anycast-gateway Gateway mac: 02e0.5200.0100 Ve10 1.1.1.0/24 Inactive (Interface Down) Ve100 100.0.0.1/24 Active device# show ipv6 anycast-gateway Gateway mac: 02e0.5200.0200 Ve100 1000::1/24 Active
Important
It is recommended that ARP suppression be configured on VLANs/BDs if static anycast gateway is configured on the corresponding VE interface. Otherwise, duplicate ARP responses to the gateway IP address are observed.
