Extreme 8820-40C Switch Features

The Extreme 8820-40C includes the following models:

8820-40C

The 8820-40C base switch includes six unused fan slots and two unused power supply slots. Fan modules and power supply modules must be ordered separately.

8820-40C-AC-F

The 8820-40C-AC-F switch includes six fan modules and two AC power supplies. Airflow for both the fan modules and the power supplies modules is front-to-back.

8820-40C-AC-R

The 8820-40C-AC-R switch includes six fan modules and two AC power supplies. Airflow for both the fan modules and the power supplies modules is back-to-front.

8820-40C-DC-F

The 8820-40C-DC-F switch includes six fan modules and two DC power supplies. Airflow for both the fan modules and the power supplies modules is front-to-back.

8820-40C-DC-R

The 8820-40C-DC-R switch includes six fan modules and two DC power supplies. Airflow for both the fan modules and the power supplies modules is back-to-front.

The front panel of the 8820-40C switch includes:

• 1 = Status LEDs
• 2 = 40 x 10/25/40/100Gb QSFP28 ports
• 3 = 10/100/1000BASE-T out-of-band management port
• 4 = Type A USB storage port
• 5 = Serial console RJ-45 port

Extreme 8820-40C Front Panel

The rear panel of the switch includes:

• 1= 6 x fan modules
• 2 = 2x power supply modules

Extreme 8820-40C Rear Panel
