The Extreme 8820-80C includes the following models:
8820-80C
The 8820-80C base switch includes four unused fan slots and four unused power
supply slots. Fan modules and power supply modules must be ordered
separately.
8820-80C-AC-F
The 8820-80C-AC-F switch includes four fan modules and four AC power supplies.
Airflow for both the fan modules and the power supplies modules is
front-to-back.
8820-80C-AC-R
The8820-80C-AC-R switch includes four fan modules and four AC power supplies.
Airflow for both the fan modules and the power supplies modules is
back-to-front.
8820-80C-DC-F
The 8820-80C-DC-F switch includes four fan modules and four DC power supplies.
Airflow for both the fan modules and the power supplies modules is
front-to-back.
8820-80C-DC-R
The 8820-80C-DC-R switch includes four fan modules and four DC power supplies.
Airflow for both the fan modules and the power supplies modules is
back-to-front.
The front panel of the Extreme 8820-80C switch includes:
1 = Status LEDs
2 = 80 x 10/25/40/100Gb QSFP28 ports
3 = 2 x 10/100/1000BASE-T out-of-band management port
