5720-48MW Switch Features

The front panel of the 5720-48MW switch includes:

• 1 = USB Micro-B console port
• 2 = USB Type-A port for management or external USB flash
• 3 = System LEDs
• 4 = Mode button
• 5 = 2 x QSFP28 Universal ports/Stacking ports (unpopulated)
• 6 = VIM slot (unpopulated)
• 7 = 48 x 100M/1/2.5/5Gbase-T 802.3bt PoE (90W) full-duplex MACsec capable ports

5720-48MW Front Panel

The rear panel of the switch includes:

• 1 = SSD slot (not used)
• 2 = 4 x Fan modules
• 3 = 10/100/1000BASE-T Out-of-band management port
• 4 = 2 x Power supply slots (unpopulated)
• 5 = Grounding lug
• 6 = Serial console port (RJ-45)
• 7 = USB Type-A port for management or external USB flash

5720-48MW Rear Panel
