VIM1-SummitStack512 Versatile Interface Module

The VIM1-SummitStack512 versatile interface module provides four 128-Gbps stacking ports that are used to cross-connect two Summit X650 series switches.

Each switch must have an installed VIM1-SummitStack512 module. To connect these ports, you must use stacking cables with compatible connectors, available from Extreme Networks.

The VIM1-SummitStack512 module requires ExtremeXOS 12.3.3 software (or later) installed on the Summit X650 series switch.

VIM1-SummitStack512 Versatile Interface Module
