Summit X460-48x Switch Ports and Slots

The front panel of the Summit X460-48x switch includes:

All the front-panel ports on the Summit X460-48x switch support Synchronous Ethernet. For information about this feature, see the . For information about SFPs, see the Extreme Networks Pluggable Transceivers Installation Guide.
10/100/1000 Mbps management port.
Serial console port used to connect a terminal and perform local management.
LEDs to indicate port status and switch operating conditions. For a description of the LEDs and their operation, see Summit X460 Series Switch LEDs.
Stack number indicator.

Summit X460-48x Switch Front Panel

The rear panel of the Summit X460-48x switch includes:

Two slots for port option cards or stacking modules (see Port Option Cards for Summit X460 Series Switches).
Replaceable fan tray.
Two power supply bays for either AC or DC power supplies (see Summit 300 W AC and DC Power Supplies).

Summit X460-48x Switch Rear Panel
