Summit X650-24t Switch Ports and Slots

The front panel of the Summit X650-24t switch includes:

• Twenty-four fixed autosensing 1000/10000 BASE-T ports (ports 1–24) that provide high-density copper connectivity.
• 10/100/1000 Mbps management port.
• Serial console port used to connect a terminal and perform local management.
• LEDs to indicate port status and switch operating conditions.

  For a description of the LEDs and their operation, see Summit X650 Series Switch LEDs.

• Stack number indicator.
