SES-Imagotag SetupNEW!

About this task

This topic outlines everything you need to consider when configuring the SES-Imagotag.

Procedure

  1. AP device considerations:
    1. Ensure that the access point is getting 3AT/3AT+ power.
    2. Connect ESL communicator to access point USB port.
    3. Ensure that the LED on the ESL communicator is red.
  2. ExtremeCloud IQ considerations:
    1. Enable SES-Imagotag on the AP Device Template or Override for a supported AP model.
      The following access points support SES-Imagotag:
      • AP305C
      • AP410C
      • AP5010
    2. Ensure that the LED on the ESL communicator is amber.

Results

Important

Important

Troubleshooting Tips:
No LED light on ESL communicator
Check the power supply. The AP requires 3AT/3AT+ power supply to work with a USB port.
The LED continues to be red
Check the AP logs to verify that ThinAP2 has started.
The LED continues to be Amber
Check the IP address of AP, the AP-ID, and the connectivity between the AP and the ESL server.
