This section documents radio interface configuration parameters applicable only to the access point profiles and devices.
The AP3000 and AP3000X access points combine powerful 802.11ax Wi-Fi 6E technology, advanced security, and ML/AI cloud management capabilities as an enterprise-class solution in a small, low-power package that allows you to deploy high speed and highly secure Wi-Fi.
AP3000/X radio specifications:
The AP50xx access point models are tri-radio access points with 6.0 GHz support.
The new AP4XX access points are tri-radio access point models.
The AP5XX access points are dual radio access point models.
Important
If the AP560h antenna-id is not configured, the radios will not operate. See antenna-id (ap560h).To enter the AP's interface context, issue the following commands:
<DEVICE>(config)#profile <AP-TYPE> <PROFILE-NAME> nx9500-6C8809(config)#profile ap505 test505 nx9500-6C8809(config-profile-test505)# nx9500-6C8809(config-profile-test505)#interface radio 2 nx9500-6C8809(config-profile-test505-if-radio2)# nx9500-6C8809(config-profile-test505-if-radio2)#? Radio Mode commands: 11axBSScolor Configure support for 802.11ax bss color 11axOFDMA Configure support for 802.11ax ofdma 11axSupport Configure support for 802.11ax mode 11axTWT Configure support for 802.11ax twt adaptivity Adaptivity aeroscout Aeroscout Multicast MAC/Enable aggregation Configure 802.11n aggregation related parameters airtime-fairness Enable fair access to medium for clients based on their usage of airtime ampdu-encapsulated-rx-amsdu Permit AMSDU to be encapsulated inside AMPDU in rx path antenna-diversity Transmit antenna diversity for non-11n transmit rates antenna-downtilt Enable ADEPT antenna mode antenna-elevation Specifies the antenna elevation gain antenna-gain Specifies the antenna gain of this radio antenna-mode Configure the antenna mode (number of transmit and receive antennas) on the radio assoc-response Configure transmission parameters for Association Response frames association-list Configure the association list for the radio beacon Configure beacon parameters bridge Bridge rf-mode related configuration channel Configure the channel of operation for this radio data-rates Specify the 802.11 rates to be supported on this radio description Configure a description for this radio dfs-rehome Revert to configured home channel once dfs evacuation period expires dynamic-chain-selection Automatic antenna-mode selection (antenna for non-11n transmit rates) ekahau Ekahau Multicast MAC/Enable extended-range Configure extended range fallback-channel Configure the channel to be used for falling back in the event of radar being detected on the current operating channel guard-interval Configure the 802.11n/ac/ax guard intervals ldpc Configure support for Low Density Parity Check Code lock-rf-mode Retain user configured rf-mode setting for this radio max-clients Maximum number of wireless clients allowed to associate subject to AP limit mesh Configure radio mesh parameters meshpoint Enable meshpoints on this radio mu-mimo Enable multi user MIMO on this radio (selected platforms only) no Negate a command or set its defaults non-unicast Configure handling of non-unicast frames off-channel-scan Enable off-channel scanning on the radio placement Configure the location where this radio is operating power Configure the transmit power of the radio preamble-short Use short preambles on this radio probe-response Configure transmission parameters for Probe Response frames radio-resource-measurement Configure support for 802.11k Radio Resource Measurement radio-share-mode Configure the radio-share mode of operation for this radio rate-selection Default or Opportunistic rate selection rf-mode Configure the rf-mode of operation for this radio rifs Configure Reduced Interframe Spacing (RIFS) parameters rts-threshold Configure the RTS threshold rx-sensitivity-reduction Configure radio receive sensitivity reduction threshold shutdown Shutdown the selected radio interface smart-rf Configure radio specific smart-rf settings sniffer-redirect Capture packets and redirect to an IP address running a packet capture/analysis tool stbc Configure Space-Time Block Coding (STBC) parameters transmit-beamforming Enable Transmit Beamforming use Set setting to use wips Wireless intrusion prevention related configuration wireless-client Configure wireless client related parameters wlan Enable wlans on this radio clrscr Clears the display screen commit Commit all changes made in this session do Run commands from Exec mode end End current mode and change to EXEC mode exit End current mode and down to previous mode help Description of the interactive help system revert Revert changes service Service Commands show Show running system information write Write running configuration to memory or terminal nx9500-6C8809(config-profile-test505-if-radio2)#
The following table summarizes the radio interface configuration commands:
| Commands | Description |
|---|---|
| 11axBSScolor | Enables and disables support for 802.11ax BSS color number addition |
| 11axFILS | Configures the 6 GHz Discovery Method FILS for the radio. |
| 11axOFDMA | Enables and disables support for 802.11ax Orthogonal Frequency Division Multiple Access (OFDMA) |
| 11axPSC | Configures PSC channels-only mode for the radio. |
| 11axRNR | Configures the 6 GHz Discovery Methods for the radio. |
| 11axSupport | Enables and disables the 802.11ax mode on AP5xx model APs. |
| 11axTWT | Enables and disables the Target Wake Time (TWT) capability on the 802.11ax AP5xx model APs. |
| 11axUmuschedBrcmOnly | Configure support for 802.11ax umusched brcm_only. |
| adaptivity | Configures an adaptivity timeout value, in minutes, for avoidance of channels detected with radar or high levels of interference |
| aeroscout | Enables Aeroscout multicast packet forwarding |
| aggregation | Configures 802.11n aggregation parameters |
| airtime-fairness | Enables fair access for clients based on airtime usage |
| antenna-diversity | Transmits antenna diversity for non-11n transmit rates |
| antenna-elevation | Configures the antenna‘s elevation gain. |
| antenna-gain | Specifies the antenna gain for the selected radio |
| antenna-mode | Configures the radio antenna mode |
| assoc-response | Enables an access point to ignore or respond to an association/authorization request based on the configured Received Signal Strength Index (RSSI) threshold and deny-threshold values |
| association-list | Associates an existing global association list with this radio interface |
| beacon | Configures beacon parameters |
| bridge | Configures client-bridge related parameters, if the selected radio‘s RF mode is set to bridge |
| channel | Configures a radio‘s channel of operation |
| data-rates | Specifies the 802.11 rates supported on a radio |
| description | Configures the selected radio‘s description |
| dfs-rehome | Reverts to configured home channel once Dynamic Frequency Selection (DFS) evacuation period expires |
| dynamic-chain-selection | Enables automatic antenna mode selection |
| ekahau | Enables Ekahau multicast packet forwarding |
| fallback-channel | Configures the channel to which the radio switches in case of radar detection on the current channel |
| guard-interval | Configures the 802.11n guard interval |
| ldpc | Enables support for Low Density Parity Check (LDPC) on the radio interface |
| lock-rf-mode | Retains user configured RF mode settings for the selected radio |
| max-clients | Configures the maximum number of wireless clients allowed to associate with this radio |
| mu-mimo | Enables multi-user multiple input multiple output (MU-MIMO) support on a radio |
| no (radio-interface-config-command) | Negates or resets radio interface settings configures on a profile or a device |
| non-unicast | Configures the handling of non unicast frames on this radio |
| off-channel-scan | Enables selected radio‘s off channel scanning parameters |
| placement | Defines selected radio‘s deployment location |
| power | Configures the transmit power on this radio |
| preamble-short | Enables the use of short preamble on this radio |
| probe-response | Configures transmission parameters for probe response frames |
| radio-resource-measurement | Enables 802.11k radio resource measurement |
| radio-share-mode | Configures the mode of operation, for this radio, as radio-share |
| rate-selection | Sets the data-rate selection mode to standard or opportunistic |
| rf-mode | Configures the radio‘s RF mode |
| rifs | Configures Reduced Interframe Spacing (RIFS) parameters on this radio |
| rts-threshold | Configures the Request to Send (RTS) threshold value on this radio |
| shutdown | Terminates or shuts down selected radio interface |
| smart-rf | Overrides Smart RF channel width setting on the selected radio interface |
| sniffer-redirect | Captures and redirects packets to an IP address running a packet capture/analysis tool |
| stbc | Configures radio‘s Space Time Block Coding (STBC) mode |
| transmit-beamforming | Enables transmit beamforming on the selected radio interface |
| use | Enables use of an association ACL policy and a radio QoS policy by selected radio interface |
| wips | Enables access point to change its channel of operation in order to terminate rogue devices |
| wireless-client | Configures wireless client parameters on selected radio |
| wlan | Enables a WLAN on selected radio |
